PO-008

Display

Monitor

21.5” LED

Display scale

16:09

Display area

478*268mm

Resolution

1920*1080

Dot pitch

0.1805×0.5415 mm

Horizontal frequency

30 － 80KHZ

Vertical frequency

60/75HZ

Color number

167.7thousands dots

Lamp Lifetime

50000 hours

Average brightness

1500cd/m 2

Contrast degree

1400 ：01

Perspective

Up/Down178°     Left/right178°

Input voltage

AC 110-220V(50HZ-60HZ)

Power management

VESA DPMS standard

Power consumption

≤120W

Working environment temperature

-20 ℃－ 60 ℃

Storage temperature

-10 ℃-50℃

Computer              specification

CPU(optional)

CORE I3  2310M  2.1GHz

RAM(optional)

4GB  DDR3L-RS - 1600MT/s

HDD(optional)

128G SSD

Graphic

Integrated Intel HD

Network card

6*RTL8111 1000M

WIFI

Support 300M, B/G/N 802.1.1

Interface

2*USB 2.0,2*USB3.0，1*LAN ,1*HDMI,1*POWER

OS support

win 7/8/8.1/10;wes 7/8;LINUX;VXWORKS

Touch screen (Infrared and capactive touch optional)

Sensing materials

Finger, pen etc. not transparent materials

Touch sensitivity

<1.5mm（center） <2.0mm（edge）

Resolution

3276 X 3276

Response time

Single touch mode:    First touch  <8ms ;     Constant touch(writing)：<3ms   Multipoint touch：    First touch<8ms ;       Constant touch(writing)<8ms      Mouse click：              First touch<8ms ;       Constant touch(writing)<8ms

Cursor speed

Single click：<300points/s  Multipoint touch : <125 points/s

Lifetime

>60,000,000 touch

Protective surface

3mm tempered glass, Anti-vandalism
