PI2001

 Modern design digital signage

Slope shape

32" to 55"

1080P HD display

Touch optional



Panel Screen size 32  43  inch
Max resolution 1920*1080
Viewing Angle 89/89/89/89
ColourBrightness 16.7M
Contrast Ratio 1600:1
Brightness 360cd/m2
Aspect Ratio 169
Response time 8ms
Input power 115W
Audio Built-in stero speakers 5W*2
Power Power input AC100-240V(power adaptor)
General
feature
Support Multi-language OSD: English, Chinese etc
Power off memory,continuous previous play when power on
Auto play when power on
Timer on/off
Preset time play
File&folder editable, rename,copy,delete file etc.
Loop playback/Slide show
background music modes,image modes,video modes (optional)
Rolling words on the screen
Support Video: MPG,MPEG-1,MPEG-2,MPEG-4,AVI,MKV,FLV,TS,VOB,TS
Support Audio: MP3,WMV
Support Photo: JPEG,BMP,GIF
Build-in SD card slot, USB port (HDMI& VGA interface optional)
USB auto update content to SD card
Security lock protect media content
 Built-in clock & calendar function
CPU option#1  CPU RK3188 , Cortex-A7, 1.0GHz ,Dual core
Storage  8G (NAND FLASH )
Memory DDR3 1G
Storage Extension Up to 32GB SD/TF Card extension, also supports SATA driver extension
WiFi High-performance WIFI 802.11b/g/n
I/O Port 2XUSB 2.0, 1XRJ45, 1 X SD, 1 XWIFI
Support OS Android Android 4.4
General information Case Material Metal case
Case Color Standard color: Black&Silver(Customized color upon request)
Storage Temp (-10 -- 50 )
Working Temp (0-- 40 )
Storage/Working  Humidity (10 -- 90 )
Product Dimension 1800*500*700mm
Product Weight 80kg
