 Capactive touch screen kiosk

 Core series powerful CPU

 POS kiosk

 All-in-one touch screen kiosk


Same quality  and  construction with Ipad

 Product size: 536mmX328mmX50mm

 Packing size:635mmX187mmX445mm

Weight:  8.5Kgs.

Specification of 21.5" ipad like all-in-one pc
Touch screen (standard)
21.5 inch capacitive touch screen
Use the most advanced capacitive touch screen, high stability, no excursion as the change of time and environment; high light transmission and no impurity, the highest is 98%±2%; long service life and durability, not afraid scratch, long life for touching; good performance, Surface hardness: 7H ; resolution: 4096*4096; single point touch more than 70 million times; plug and use, no need to install any drive; support dual-touch under window 7; with free handwriting software; location accuracy less than 2.5mm.
21.5 inch (16:9) LED panel
Use 21.5 inch LED panel; Resolution: 1920*1080; Pixel pitch: 0.248mm; Brightness: 250cd/; Contrast ratio: 1600:1; Response time: 5ms; View angle: 160°/160° (horizontal/vertical); Active area: 476.64mm*268.11mm; Shell material: ABS
PC configuration
Low PC configuration
CPU: Intel Dual-Core D2550; Integrate Intel GMA3650 Graphics card; RAM DDR3 4G, 320G HDD, 1*HDMI port, 1*VGA Port , 4*USB Port , 1*12VDC input, 1*RJ45 Port, 1*Audio I/O port
High PC configuration
CPU: i3-2367M Intel Core I3-2317M; Integrate Intel HD Graphics 3000 Graphics card; RAM DDR3 4G, 320G/7200 HDD, 1*HDMI port, 1*S/PDIF Port, 1*VGA Port , 2*USB Port , 1*12VDC input, 1*RJ45 Port, 1*Audio I/O port
(To achieve better operating experience, this configuration recommended)
Operating system
Windows 7 (The buyers provide the operating system Window 7, we install for buyers )
Working environment
Temperature -30℃-+70℃, relative humidity 10%-90% (relative, non-compression)
Storage temperature
Power supply
Input:110-240V, 50-60HZ; Output:12.0V-4.16A
Physical size
Packing size
Products functions
1. No pedestal design, the display does not swag when being touched on the desk, with good stability.
2. Own mold, the level of technology in line with international standards; use of ergonomic and aesthetic Principles of design.
3. Light and handy and ultra-thin fashion design, greatly expanded the field of computer application area; Convenient angle adjustment, the touch screen can be randomly adjusted in the range of 15°-90°.
